Hollowcore Slab

The IMPACT Hollowcore module helps you design and detail hollow core slabs in 3D, including automatic cast in lifting items centre of gravity positioning with automatic core fillings. It generates automatic shop drawings and export files for plotters; automatic sawing machinery and reports.

Design and detail hollow core slabs in 3D, including automatic cast in lifers positioning with automatic core fillings
Generate automatic shop drawings
 Export files for plotters
Automatic sawing machinery
Automatic drainage holes
Detailed reports.
Use in combination with AutoCAD, BricsCAD, and Revit.

Features of the IMPACT Hollow-core module include but are not limited to cast-in materials; recesses; edge details, positioning of prestressed wires/strands; cut zones, and much more. It is even possible to perform prestress load checks on your floor layouts with the PRE-Stress Connection module.

The IMPACT Hollowcore module helps you design and detail hollowcore slabs in 3D, including automatic cast in lifers positioning with automatic core fillings. It generates automatic shop drawings and export files for plotters; automatic sawing machinery and reports.

Watch a Quick Overview Video

Any changes you make in the 3D model, plan, elevation or on the shop drawing, are immediately updated on all corresponding drawings and models. Your whole hollowcore slab design project is synchronised with all drawings automatically updated at all times.

Hollow core slab shop drawing produced with the IMPACT design software

Features IMPACT Hollowcore includes but is not limited to cast-in materials; automatic recesses; recesses; edge details, positioning of prestressed wires/strands; cut zones, core fillings, hanger details, and much more.

It is even possible to perform prestress load checks on your floor layouts with the PRE-Stress Connection module.

IMPACT Hollowcore can be used and purchased as a standalone module or part of the entire IMPACT Design Suite, including all design tools.

IMPACT Hollowcore is a feature for both IMPACT for AutoCAD, BricsCAD, and IMPACT Revit.
