Load Cases

The PRE-Stress software displays load cases that will be applied to load combinations. Just like defining the section shape geometry, loads are defined through the graphical interface. You can set uniform loads, trapezoidal loads, point loads, temperature loads and self weight on all types of prestressed concrete elements.

It is recommended that you define the different load cases that are to be used at earliest opportunity. Once load cases have been defined, they will be shown in the main program window, in a pull-down menu on the right-hand side of the status bar.

PRE-Stress Load Cases

For the loads you can define load type, direction, magnitude (P), placement (L), eccentricity (e, optional), load width (b, optional) and eccentricity reference (optional). These loads are added to the selected, previously defined, base load case. One of the base load cases defined above must be selected in order to state a load that will operate upon the construction.

Why wait?  Apply below to download a trial license of PRE-Stress and get started on your journey today!

PRE-Stress Wiki

For more in depth information on defining loads please visit the PRE-Stress Wiki by clicking here.
