Design & Analysis Software for
Prestressed Concrete Elements
Prestressed Sloped Beam Design with PRE-Stress
PRE-Stress can help you with Prestressed Sloped Beam design & analysis. You can study the precast concrete roof beams behaviour under torsion by applying loads with eccentricity and get an automatic detailed report of the internal forces to Eurocode. It the perfect software program for designing different types of prestress beams including “sloped” “I” Beams.
Watch a Quick Overview Video about Prestressed Sloped Beam Design
Prestressed Sloped Beam Design Features
Configure your variable cross-section for the prestressed sloped beam design by setting the dimensions of the element. You can set the slope and customise intermediate cross sections.
The strands are easily added and positioned manually or through the use of the Reinforcement Pattern Manager. The reinforcement bars at the top are automatically adjusted to the slope of the top edge. Using the full bond option you can ensure that the bars are connected over the mid-span.
The self-weight is automatically applied for the element. Depending on the type select for the load. The program will automatically add the correct factors according to the National Annex and generate the load combinations.
After a successful code control it is possible to design the recesses in the ends of the beam.
Get a full documentation report for your sloped I Beam calculation in seconds, with all the verifications including fire calculation.
Press on the Get a Free Trial button to apply for a trial or contact your local Sales Representative for more information.
Why wait? Click to get an automated, 2 x week free trial of PRE-Stress, and get started today!
PRE-Stress Wiki
For full technical information, User Guides on Prestressed Sloped Beam design please visit the PRE-Stress Wiki by clicking here.
Calculations performed according to:
EuroCode- British National Annex
- Danish National Annex
- Finnish National Annex
- Norwegian National Annex
- Swedish National Annex
EuroCode
British National Annex
Danish National Annex
Finnish National Annex
Norwegian National Annex
Swedish National AnnexPRE-Stress Blog
